HDMI / SDI 4K CROSS CONVERTER
with Scaling and Frame Rate Conversion
The 12G-CROSS is a small (4.2″ x 5.1″ x 1.2″) low power portable converter encased in a solid robust aluminium case and does not contain a noisy fan. Allowing it to be used in almost any environment.
Allows either of the HDMI or SDI outputs to be simultaneously sourced from either the HDMI or SDI input or the new 4K scaling engine.
Supports 294 VESA formats via HDMI input
The 4K scaling engine can be driven by either the SDI or HDMI input, supports horizontal and/or vertical flipping and can be locked to either the SDI, HDMI or Genlock input.
The 4K scaling engine can scale and/or frame rate convert between 351 input formats and 57 output formats. The supported formats are:
294 VESA formats in via HDMI input
(3840 or 4096) x 2160p50/59.94/60 via HDMI or 12G-SDI
(3840 or 4096) x 2160p30/29.97/25/24/23.98 via HDMI or 6G-SDI
(1920 or 2048) x 1080p50/59.94/60 via HDMI or 3G-SDI (Level A or B)
1920 x 1080i60/59.94/50 via HDMI or HD-SDI
(1920 or 2048) x 1080p30/29.97/25/24/23.98 via HDMI or HD-SDI
(1920 or 2048) x 1080psf30/29.97/25/24/23.98 via HD-SDI
1280 x 720p60/59.94/50/30/29.97/25 via HDMI or HD-SDI
1280 x 720p24/23.98 via HD-SDI
720 x 480p59.94 or 720 x 576p50 via HDMI
720 x 480i59.94 (NTSC) or 720 x 576 (PAL) via HDMI or SD-SDI
That is an amazing 20,007 possible format conversions!
The audio pairs in the SDI and HDMI outputs can be rearranged as required.
Includes 4 x (3G/HD/SD)-SDI outputs, that allow it to be used as a 1 to 4 distribution amplifier.
The 12G-CROSS is a truly portable product that incorporates an easy-to-use LCD screen and button control system. This gives easy access to the outstanding features without using complicated LED/button controls, dip switches, or having to carry around a computer to change a simple setting.
SWIT S-4609 Overview
S-4609 is a portable mini converter of SDI audio de-embedder, supports up to 3 Gb/s SDI, and can be widely used in broadcast field production and professional audio/video conversion and transmission.
Portable SDI to audio de-embedder
Output AES/EBU audio
Output 6.35 mm balanced audio
Provide 2x SDI loop output
Power/input/output status indicator
Heavy duty aluminum housing
Bottom screw threads for installing
De-embed channel selection by 6 switchers
S-4609 can de-embed any 2-ch audio from SDI first 8-ch embedded audios. User can select the channel number to be de-embedded by the 6 switchers on the front panel of the product. And on the rear side, S-4609 provides the description of the 6 switchers for reference.
S-4609 provides 3 LED indictors, to check if the power is connected, if the SDI input is recognized, and if de-embedded audio is delivered.
The S-4609 mini converter adopts unibody aluminum alloy housing, strong for field using and protects the audio/video connectors effectively.
