SWIT S-4609 Overview
S-4609 is a portable mini converter of SDI audio de-embedder, supports up to 3 Gb/s SDI, and can be widely used in broadcast field production and professional audio/video conversion and transmission.

Key Features
Portable SDI to audio de-embedder
3G/HD/SD-SDI supported
Output AES/EBU audio
Output 6.35 mm balanced audio
Provide 2x SDI loop output
Power/input/output status indicator
Heavy duty aluminum housing
Bottom screw threads for installing
De-embed channel selection by 6 switchers
S-4609 can de-embed any 2-ch audio from SDI first 8-ch embedded audios. User can select the channel number to be de-embedded by the 6 switchers on the front panel of the product. And on the rear side, S-4609 provides the description of the 6 switchers for reference.
Status indicators
S-4609 provides 3 LED indictors, to check if the power is connected, if the SDI input is recognized, and if de-embedded audio is delivered.
Heavy-duty housing
The S-4609 mini converter adopts unibody aluminum alloy housing, strong for field using and protects the audio/video connectors effectively.

Saadavus: Saadaval järeltellimisel Tootekood: 6948193501888 Kategooria:
  • Kirjeldus
  • Lisainfo


SWIT Portable SDI Audio De-Embedder


SWIT S-4609 Specs

Type Audio embedder
Width 3.9 in
Depth 3.3 in
Height 1.1 in
Weight 8.29 oz
Low Voltage Power DC 6 – 18 V
Terminals (1) x 3G HD-SDI input – BNC
(1) x balanced audio input – phone stereo 6.3 mm x 2
(2) x 3G HD-SDI output
(4) x balanced audio input
(1) x AES / EBU input
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 122 °F
Humidity Range Operating 10 – 90%
Packaging Info
Package Weight 1.2 lb
Box Dimensions (LxWxH) 6.457 x 4.803 x 2.992″
