Panasonic AW-HE40HWEJ9 HD integrated camera and PTZ – HDMI Version

Panasonic AW-HE40HWEJ9 HD integrated camera and PTZ – HDMI Version

2 790,00

Panasonic AW-HE40HWEJ9 HD integrated camera and PTZ – HDMI Version

Saadavus: Saadaval järeltellimisel Tootekood: 5025232804474 Kategooria:
Võrdle
  • Kirjeldus

Kirjeldus

Panasonic AW-HE40HWEJ9 HD integrated camera and PTZ – HDMI Version
• 1/2.3 type MOS
• 30 x Optical Zoom (10 x Digital Zoom + Digital Extender)
• Night Mode (IR Light needed)
• Audio Input – 3,5mm stereo mini jack (Line or Mic)
• IP control with image monitorig output
• RS422, RS232C In/Out
• IP Connection (RJ45)
• Pearl White (W)
• PoE+ Support
• H264 HD-IP streaming
• Internal SD card recording and playback
• USB video class output (1920×1080), backup camera settings AW-RP120 / AK-HRP200


Dimensions (W x H x D) 160 mm x 186 mm x 166 mm
(6-5/16 inches x 7-41/128 inches x 6-17/32 inches)
[excluding protrusions, direct ceiling mount bracket]
Storage Temperature –20 °C to 50 °C (–4 °F to 122 °F)
Current Consumption 1.2 A (Supplied AC adaptor)
0.4 A (PoE+ power supply)
Power Requirements DC 12 V (Supplied AC adaptor)
DC 42 V to 57 V (PoE+ power supply)
Ambient Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Finish [AW-HE40HWPJ9], [AW-HE40SWPJ9], [AW-HE40HWEJ9], [AW-HE40SWEJ9] Pearl white
[AW-HE40HKPJ9], [AW-HE40SKPJ9], [AW-HE40HKEJ9], [AW-HE40SKEJ9] Metallic black
Allowable Humidity Ranges 20 % to 90 % (no condensation)
Mass Approx. 1.5 kg (3.30 lb)
Controller Supported*1 AW-RP50, AW-RP120, AK-HRP200
Input Mic/line input
Stereo mini-jack (ø3.5 mm)
Input impedance: Approx. 2 kΩ (unbalanced)
[Mic input] Supported microphones: Stereo mic
(plug-in power, on/off switching via menu)
Supplied voltage: 2.5 V ± 0.5 V
Mic input level: –60 dBV ± 3 dBV
[Line input] Input level: -10 dBV ± 3 dBV
Output Video output
HDMI: [AW-HE40HW/HK] HDMI connector
* HDCP is not supported. * VIERA Link is not supported.
HD SDI OUT: [AW-HE40SW/SK] Compliant with the SMPTE292M standards/75 Ω(BNC x 1)
Input/Output Input/Output connector
LAN: LAN connector for IP control (RJ-45)
Equipped with straight/crossover cable auto detection function
RS-232C: Mini DIN 8-pin (IN) Mini DIN 8-pin (OUT)
RS-422: CONTROL IN RS422A (RJ-45)
USB: Mini-B port
SD card: microSD card slot
Lens Motorized 30x zoom, F1.6 to F4.7
[f=4.3 mm (11/64 inches) to 129 mm(5-5/64 inches); 35 mm (1-3/8 inches)
equivalent: 31.6 mm (1-31/128 inches)to 962.0 mm (37-7/8 inches)]
Minimum Illumination 59.94 Hz:
0.7 lx (50 IRE, F1.6, 48 dB,1/60 without accumulation)
0.35 lx (50 IRE, F1.6, 48 dB,1/30 with accumulation[Frame Mix 6 dB])
50 Hz:
0.7 lx (50 IRE, F1.6, 48 dB,1/50 without accumulation)
0.35 lx (50 IRE, F1.6, 48 dB,1/25 with accumulation[Frame Mix 6 dB])
Synchro Scan 59.94 Hz : 59.94 Hz to 660.09 Hz
50 Hz : 50.00 Hz to 570.12 Hz
Horizontal Resolution 1000 TV lines Typ (Center area)
White Balance AWB A, AWB B, ATW, 3200K,5600K, VAR (2400K to 9900K)
Color Separation Optical System On-chip color filter system
Focus Switching between auto and manual
Focus Distance Entire zooming range:1.2 m (3.94 ft)
Wide end: 10 cm (0.33 ft)
Gamma Off, Normal (Low, Mid, High), Cinema
Electronic Shutter Speed During Full Auto:1/30 to 1/2000 [59.94 Hz], 1/25 to 1/2000 [50 Hz] During Auto: 1/60 to 1/2000 [59.94 Hz], 1/50 to 1/2000 [50 Hz] DuringManual:1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 [59.94 Hz], 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 [50 Hz]
Imaging Sensors 1/2.3-type MOS
Gain Selection*2 Auto, 0 dB to 48 dB (3 dB step)
Frame Mix*3 Auto, Off, 6 dB, 12 dB, 18 dB, 24 dB
Recording Format 1920 x 1080/59.94p, 1920 x 1080/50p, 1920 x 1080/29.97p,
1920 x 1080/25p, 1280 x 720/59.94p, 1280 x 720/50p,
1280 x 720/29.97p, 1280 x 720/25p
Frame Rate max 30 fps (System frequency 59.94 Hz)
max 25 fps (System frequency 50 Hz)
Audio Output USB Audio Class Ver1.0
Video Output USB Video Class Ver1.0
Resolution 1920 x 1080, 1280 x 720, 640 x 360
Output Format HD
1080:59.94i/50i
1080:29.97p/25p
1080:29.97PsF/25PsF
720:59.94p/50p
Scene File Full Auto, Manual1, Manual2, Manual3
Synchronization System Internal synchronization
Pan/Tilt Operation Speed Maximum speed during preset: 300°/s
Maximum speed during manual: 90°/s
Panning Range ±175°
Quietness During preset: NC40 or less
During manual: NC35 or less
Tilting Range –30° to 90°*5
Chroma Amount Variability ±3 step
System Frequency 59.94 Hz/50 Hz
Installation Method Stand-alone (Desktop) or suspended (Hanging)*4
Supported Models Devices standardly equipped with a USB 2.0 compatible port
IP Connecting Cable When connecting through a hub:
LAN cable*6 (category 5 or above),max. 100 m (328 ft)
When using a PoE+ hub:
LAN cable*6 (category 5e or above),max. 100 m (328 ft)
When a hub is not used:
LAN cable*6 (category 5 or above),max. 100 m (328 ft)
AW Protocol Connecting Cable LAN cable*6 (category 5 or above,straight cable), max. 1000 m (3280 ft)
Standard Protocol Connecting Cable Mini DIN 8-pin cable, male
SD Card Type micro SDHC (4 GB to 32 GB), micro SDXC (64 GB to 128 GB), Speed class 10 or higher
Video Compression Format (SD) MPEG-4 AVC/H.264 High Profile
Audio Compression Format (SD) AAC-LC (48 kHz, 16 bit, 2 ch, 128 kbps)
SD Card Recording MPEG-4 AVC file standard compliant (.MP4)
Accessories Supported protocol
Mount bracket for installation surface (Hanging*7 / Desktop): 1
Drop-prevention wire (already attached to the unit): 1
Bracket mounting screws (bind-head) M4 x 10 mm: 4
Main unit mounting screw (with flat washer, spring washer) M3 x 6 mm: 1
Power cable (1.5 m [4.92 ft]): 1
AC adaptor: 1
CD-ROM: 1
Supported Protocol IPv4:
TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, FTP, DHCP, DNS, NTP, IGMP, UPnP, ICMP, ARP, RTSPoverTCP, RTSPoverHTTP, SSL(TLS), MultiCast/UniCast
IPv6:
TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, FTP, DHCPv6, DNS, NTP, ICMPv6(MLD), RTSPoverTCP, RTSPoverHTTP, SSL(TLS), MultiCast/UniCast
Note * 1: It may be necessary to upgrade the version of the controller so that the controller will support the unit.
* 2: During Auto, 6 dB to 48 dB (6 dB step) are available for AGC Max Gain setting.
* 3: During Auto, 0 dB, 6 dB, 12 dB and 18 dB are available for Auto F.Mix Max Gain setting.
* 4: To ensure safety, the unit must be secured using the mount bracket supplied.
* 5: Depending on the pan or tilt position, the camera may be reflected in the image.
* 6: Use of an STP (shielded twisted pair) cable is recommended.
* 7: To ensure more safety, AW-HE40 series can be secured by using the direct ceiling mount bracket (WV-Q105A).
Resolution (Network) JPEG:
VGA (640 x 360), QVGA (320 x 180) max.30 fps
1920 x 1080, 1280 x 720, 640 x 360, 320 x 180 max.30 fps
H.264:
1920 x 1080, 1280 x 720, 640 x 360, 320 x 180 max.60 fps
iOS, Android Support JPEG image display
