SWIT S-4607 Overview

With the S-4607 mini converter, you can convert SDI to LC single mode optical fiber, and convert optical fiber to SDI simultaneously. It’s widely used on transmitting SDI in a long distance and bi-directionally. The S-4607 has heavy-duty housing design, protecting the BNC connectors well, and supplied various screw threads in the bottom, for convenient installing.

Key Features

  • Portable optical fiber converter
  • Bi-directional optical fiber SDI and SDI to optical fiber
  • Single-mode optical fiber, LC connector
  • Support hot-swap of optical module
  • Power/SDI input status indicator
  • Heavy duty aluminum housing
  • Bottom screw threads for installing

SWIT S-4607 Specs

Device Type Video extender
Form Factor External
Connectivity Technology Wired
Optical Wave Length 1310 (TX) / 1260-1580 (RX) nm
Max Transfer Distance 12.4 miles
Status Indicators Power, status
Features Bidirectional
Expansion / Connectivity
Interfaces 1 x video (input) – BNC
1 x video (pass-through) – BNC
2 x video (output) – BNC
1 x network – LC single-mode
Power Device External power adapter
Power Consumption Operational 4 Watt
Dimensions & Weight
Width 3.9 in
Depth 3.3 in
Height 1.1 in
Weight 8.82 oz
Manufacturer Warranty
Service & Support Limited warranty – 2 years
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 158 °F
Humidity Range Operating 10 – 90%
