The DW3020 is a flush mount wall panel controller designed to work in combination with the R2 amplifier. It can be installed in a separate zone, and gives the possibility to select the desired audio source and adjust the volume for the zone that it’s applied to. The connection between the amplifier and the controller is made by using standard UTP CAT5 cabling with RJ45 connectors.
The MSP40 is a professional media player/recorder supporting a wide variation of compressed and lossless audio formats. Playback of MP3, OGG, AAC, FLAC, WMA and WAV is possible in numerous bit rates, while recordings are possible in MP3, OGG and WAV file types. The front panel of the system accomodates a 2.8” TFT display in combination with a push rotary function dial and 4 tactile pushbuttons. The controls and indicators on the front panel of the unit are guaranteeing an intuitive and user friendly operation, allowing hassle free operation and configuration to even unexperienced users. All media information including track, artist, playback mode, … are indicated on the graphical user interface, while playback modes are selectable between single or continous play and various repeat and random play modes are available. Both the balanced stereo line output (playback) and the balanced stereo line input (recording) are implemented using two 3-pin terminal block connections. The USB media carrier shall be inserted to the USB socket on the front panel of the unit. The RS-232 communication port allows system integration with any home or industrial automation system, while an optional 2.4 GHz remote control allows handheld control while hidden out of sight.
The AUDAC TR266 is a super shielded true isolation audio transformer which is especially designed to be used in highly polluted EMI environments. Hum in audio systems is usually caused by ground loops in the system. A common mode current will flow in a ground loop created by an electrical system that has grounds on different voltage potentials. This results in a 50 Hz hum in the audio signal.The most common method to solve these problems is an audio transformer. The AUDAC TR266 audio isolation transformer with an in- and output impedance of 600 Ohm and a turns ratio of 1 : 1 has a very wide bandwidth and very low distortion which ensures a non distorted bass response and non attenuated high frequencies. Thanks to its MU-metal shielding, it can guarantee the best performance in even the most EMI polluted environments. MU-Metal is a soft ferromagnetic material with a very high magnetic permeability. It consists of an alloy of Nickel, Iron, Copper and Molybdenum. MU-Metal has a magnetic shielding effectiveness going from 100x up to 1000x higher than steel of equivalent thickness. It is especially good in 50/60hz type applications where all other shieldings fail. The TR266 super shielded transformer can be used for applications where the shielding of standard transformers becomes inadequate. A typical example of such an application is the broadcast system in railway stations.
The CSE55 is a professional ceiling speaker with an integrated red LED unit which can be used as visible alarm signal. It features a 4 1/3″ single cone loudspeaker which is capable of producing up to 10 Watt RMS with a maximum of 20 Watt and it ensures good reproduction of speech and background music in all situations. The speaker is fitted with a 100V line transformer and different power taps are available for 6 Watt, 3 Watt and 1.5 Watt at 100V. The integrated LED unit delivers a light intensity of 24 Lumen on a supply voltage of 24V DC.
The MBK112 series mounting brackets are especially designed for the mounting of the AUDAC PX series speakers. These black brackets allow mounting the speakers in any possible situation. For the mounting of the PX series speaker with the corresponding bracket, the pole flange adapter in the bottom of the speaker has to be replaced with a screw flange adapter, which is included. They are constructed of solid steel, and come with all the necessary parts for safe mounting, such as 2 M10 bolts and a safety cable with M10 eye bolt mounting. This bracket is also available in white, MBK112/W
Thanks to this 35mm adapter piece you can place KYRA series column speaker effortlessly on any speaker stand. The MBK250 consists of the 35mm adapter piece, wing nut to fasten the adapter to a 35mm speaker pole and a large screw that can fix the original column speaker bracket to the adapter.
The PC3000 is a flush mount wall program selector for 100V PA installations. It is compatible with AUDAC, Niko, Legrand and other standard 45 x 45 mm installation materials. The output can be selected out of 5 different sources using the rotatable dial. Due to it’s slim and good looking design, these program selectors will blend into all kinds of different environments or interiors. The construction of the PC3000 is made with sturdy ABS and therefore suitable for big projects in industrial buildings to the standard installation into home design interiors. The connections are made at the rear side, using screw terminal blocks. Matching coverplates for the PC3000 are separately available (CP45CF). Available in Black (/B) and White (/W).
The CPB series are heavy duty splash waterproof speaker bags especially designed for the protection and handling of the AUDAC PX and RX speakers in all possible situations. The design ensures that it is possible to reach the connections, place the speaker on a stand and carry the speaker using the speaker handles even when the cover bag is attached. When not used, all these openings can be covered with a stitched flap from the same material. The front of the bag can be opened with a zipper to use the speaker without removing the bag. During transportation and storage, the front can be closed to avoid any damage to the speaker. The bags are made out of extra strong, water repelling polyester with heavy duty stitching and are finished with small rubber feet. The inside has a special soft coated protection to avoid structural damages.
